• Dual ceramic ball bearing system provides optimal turbo response & better durability by reducing the shaft-motion
• 9 Blade G-Aero billet compressor wheel with extended tapered tip technology
• 9 Blade G-Aero Inconel 713c turbine wheel
• Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
• Compressor Wheel: 68*84mm
• Turbine Wheel: 68*62mm
• Compressor Inlet: 4” Hose
• Compressor Outlet: 2.5” V-Band
• Turbine Inlet: T3/T4
• Turbine Outlet: 3” V-Band
• Water Ports: 2-M14 x 1.5
• Oil Feed: 7/16-24 UNF with a -4AN Restrictor Pre-installed
• Oil Drain: Std T3
• Turbine husing: Dual vband 1.01A/R

Replaces OE part number:

880696-5002S

740902-0116

740902-0112

740902-0113

740902-0114

740902-0115

Turbochargers come high speed trim balanced ready to use and include fitting hardware.

Remember, buying your 6862G performance ball bearing turbochargers from us means you receive:

• a complete BRAND NEW turbocharger
• a full hardware install kit*
• a full VAT invoice
• NO import charges, duty fees or other hidden charges (UK CUSTOMERS ONLY)
• 12 Months UK-based Warranty

As a turbocharger specialist, we can offer FULL servicing and repair services to the Pulsar Turbo range of units.

7-10 WORKING DAYS DISPATCH

*where available
