• Dual ceramic ball bearing with steel cage provides optimal turbo response &
  better durability by reducing the shaft-motion
• 71mm inducer 10 Blade G-Aero billet compressor wheel with extended tapered tip technology
• 9 Blade G-Aero Inconel 713c turbine wheel
• Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor and pressure ports
• Water fittings included with the super core
• 2 Turbine Housing options
• HP rated at 1150HP at the flywheel
• Suitable engine size: 2.0-6.0L

Description

• Compressor Wheel: 71*88mm
• Turbine Wheel: 77*70mm
• Compressor Inlet: 4″ Hose
• Compressor Outlet: 2.5″ V-Band
• Turbine Inlet: T4 divided
• Turbine Outlet: 4″ V-Band
• Water Ports: -6AN
• Oil Feed: Flange Required (Recommended size: -4AN Std T4 Flange )
• Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’)
• 2 Turbine Housing options: T4 (Divided) 0.95 A/R, 1.06 A/R

Turbochargers come high speed trim balanced ready to use and include fitting hardware.

Remember, buying your 7170G performance ball bearing turbochargers from us means you receive:

• a complete BRAND NEW turbocharger
• a full hardware install kit*
• a full VAT invoice
• NO import charges, duty fees or other hidden charges (UK CUSTOMERS ONLY)
• 12 Months UK-based Warranty

As a turbocharger specialist, we can offer FULL servicing and repair services to the Pulsar Turbo range of units.

7-10 WORKING DAYS DISPATCH

*where available
